SPECIFICATION

• Output power (20-20KHz/THD≤1%) : 350W×2

• Output power (20-20KHz/THD≤1%) : 530W×2

• Bridge 8Ω : 1060W

• Connection : XLR, TRS interface

• Voltage gain (@1KHz) : 34.4dB

• Input sensitivity : 0.775V/1V/1.44V

• Input impedance : 10KΩ unbalanced, 20KΩ balanced

• Frequency response(@ 1W power) : 20-20KHz/+0/-2dB

• THD+N(@1/8 power) : ≤0.05%

• SNR (A-weighted) : ≥90dB

• Damping coefficient (@ 1KHz) : ≥200@ 8Ω

• Resolution (@1KHz) : ≥80dB

• Protection method : Over current protection, DC protection, short circuit protection

• Indicator : Power, protection, distortion

• Cooling method : Fan cooling

• Power supply : ~220V, 50Hz

• Maximum power consumption : 1600W

• Size : 483×394×88mm

• Weight : 12.6Kg
