Specification

• Image Sensor : 5 MP CMOS

• Signal System : PAL/NTSC

• Max. Resolution : 2560 (H) × 1944 (V)

• Lens Mount : Φ14

• Day & Night : IR Cut Filter

• Lens Type : 2.7 mm to 13.5 mm motorized varifocal lens

• Supplement Light Range : IR: Up to 40 m

• Day/Night Mode : Auto/Color/BW (Black and White)

• Wide Dynamic Range (WDR) : Digital WDR

• Image Parameters Switch : STD/HIGH-SAT

• White Balance : Auto/Manual

• Image Enhancement : DWDR ,BLC ,HLC ,Global

• Noise Reduction : 2D DNR

• Protection : IP67

• Image Settings : Brightness, Smart IR, Sharpness, AGC

• Video Output : Switchable TVI/AHD/CVI/CVBS

• Power :  12 VDC±15%, 24 VAC±15%, Max 8.8 W

• Dimension : 84.5 mm × 92 mm × 255.1 mm (3.33" × 3.62" × 10.04")
