Specification

• Image Sensor : 5 MP CMOS

• Signal System :  PAL/NTSC

• Max. Resolution : 2560 (H) × 1944 (V)

• Lens Mount : Φ14

• Day & Night : IR Cut Filter

• Angle Adjustment : Pan: 0° to 355°, Tilt: 0° to 75°, Rotation: 0° to 355°

• Lens Type : 2.7 mm to 13.5 mm motorized varifocal lens

• Supplement Light Range : IR: Up to 40 m

• Day/Night Mode : Auto/Color/BW (Black and White)

• Wide Dynamic Range (WDR) : Digital WDR

• Image Parameters Switch : STD/HIGH-SAT

• White Balance : Auto/Manual

• Image Enhancement : DWDR, BLC ,HLC ,Global

• Noise Reduction : 2D DNR

• Protection : IP67

• Image Settings : Brightness, Smart IR, Sharpness, AGC

• Video Output : Switchable TVI/AHD/CVI/CVBS

• Power : 12 VDC±15%, 24 VAC±15%, Max 5.9 W

• Dimension : Ø145 mm × 111.3 mm (5.69" × 4.37")
